Grasp and pull the retard roller cover with your fingers to remove it.Removing and Reinstalling the Retard Roller Always be sure to check that the roller cover is closed. Push the roller lock lever up to lock the feed roller.įailure to firmly close the roller cove may cause a feed error.Put the feed roller in place (1), and align the notch in the roller's axle with the shaft on the scanner (2).Slide the feed roller to the right, and then pull them towards you.Removing and Reinstalling the Feed Roller Always be sure to check that the roller holder and roller cover are closed. Make sure to hear a latching sound and that it is securely returned to its original position.įailure to firmly close the roller holder and roller cover may cause a feed error.
Canon dr 3080cii roller kit install#
Install the Pickup Roller so that the side with the gear is on the left. Remove the pickup roller, and set a clean pickup roller or a replacement pickup roller.The roller holder returns to its original position when released. Removing and Reinstalling the Pickup Roller Deformation of the rollers may cause feed errors. Do not place excessive force on the rollers when removing or reinstalling the rollers. Leaving the power turned ON may result in an electric shock. Turn OFF the power switch, and disconnect the power plug from the power outlet when you remove or reinstall the rollers. Removing and Reinstalling the Rollers Pickup Rollerįollow the procedure shown below to remove and reinstall the rollers when you need to clean or replace the Pickup, Feed, or Retard Rollers.
